Ratchet System ：THR CVR
Ratchet Gear：60T
O.L.D:100/110/142/148mm
O.L.D:100/Hole:Front28H/Rear28H
|
Specification |
Hub Model:M3 |
www.bike.cycle.com |
|
Item |
Part |
Description |
|
Material |
Hubshell |
7075 T651 AL Alloy |
|
|
Axle |
|
|
|
Cassette body |
|
|
Figure
|
Axle P.C.D |
Front17mm/Rear17mm |
|
|
Flange P.C.D |
Front:Disc42mm/Non29mm Rear:Disc/Drive 52mm |
|
|
O.L.D |
100/110/142/148mm |
|
|
WR rear |
142=23.5mm/148=27mm |
|
|
The Distance From Drive Side Bearing to Frame |
53.8mm |
|
|
Hole |
Front28H/Rear28H |
|
|
Plait |
X3 Cross-over |
|
Bearing |
Brand |
Japan EZO steel ball |
|
|
Sealed bearings |
Front6803*2/Rear6903*2/Casstte6803*2 |
|
Cassette Ratchet System |
Ratchet Type |
THR CVR AL alloy Ratchet |
|
|
Ratchet Gear |
60T |
|
|
Angle |
6° |
|
Side Axle System |
Interface |
Straight Pull quick release axle with bearing pre-compaction adjust |
|
|
Side installation |
Plug-in |
|
Seal |
4pcs |
|
|
Cassette body model |
HG/XD/MS |
|
|
Usage Road |
XC/TR |
|
|
Weight |
Front 84+Rear162=246g |
|
|
Summarize |
Extremely lightweight Smooth/Simple/Fast
|
|
