0011Cycle II Bearing removal tool
7075 Aliumimum alloy anode material+harden stainless steel
| 0011 Cycle II Bicycle Hub Bearing Removal Tool | ||||
| Specification | ||||
| Item | Installation Support | Disassembly Support | Size(mm) | Hub/Middle Axle |
| 6801 | √ | √ | 10×19×7 | Hub |
| 6802 | √ | √ | 15×24×5 | Hub |
| 6803 | √ | √ | 17×26×5 | Hub |
| 6804 | √ | √ | 20×32×7 | Hub |
| 6805 | √ | 25×37×7 | Hub | |
| 6806 | √ | 30×42×7 | Hub | |
| 6808 | √ | 40×52×7 | Hub | |
| 6900 | √ | √ | 10×22×6 | Hub |
| 6901 | √ | √ | 12×24×6 | Hub |
| 6902 | √ | √ | 15×28×7 | Hub |
| 6903 | √ | √ | 17×30×7 | Hub |
| 6904 | √ | √ | 20×37×9 | Hub |
| 6000 | √ | √ | 10×26×8 | Hub |
| 6001 | √ | √ | 12×28×8 | Hub |
| 15267 | √ | √ | 15×26×7 | Hub |
| 17287 | √ | √ | 17×28×7 | Hub |
| 18307 | √ | √ | 18×30×7 | Hub |
| 2437 | √ | × | 24×37×7 | Middle Axle |
| 1.Other outer bearing the same outer/inner diameter also support press-in/disassembly,10mm bearing needs metal gasket knock in for installation and removal,12/15/17/20mm axles should statics disassembly. | ||||
| 2.Support hub axle have drvie ring /non,cassette have pad ring /non disassembly. | ||||
| 3.standard configuration 2sets hand shanks:installation hand shank 2sets,removal 1set,pressing block 1pcs . | ||||
| 5.The hand shank is 7075 Aluminum alloy anode material,the thrust bearing and lock block use stainless steel harden treating,choose the POM metal gasket for protect the hub. | ||||
| 6.Warranty:2 Years. | ||||
