Ratchet System ：THR SSF
Ratchet Gear：45/72T
O.L.D:110/148mm
Hole：Front28H/Rear32H
|
Specification |
Hub Model:M2 elbow
|
www.bike.cycle.com |
|
Item |
Part |
Description |
|
Material |
Hubshell |
7075 T651 AL Alloy |
|
|
Axle |
|
|
|
Cassette body |
Stainless Steel/Titanium Alloy |
|
Figure
|
Axle P.C.D |
Front17mm/Rear17mm |
|
|
Flange P.C.D |
Front:Disc62mm/Non45mm Rear:Disc62mm/Non62mm |
|
|
O.L.D |
110/148mm |
|
|
WR rear |
142=23.5mm/148=27mm |
|
|
The Distance From Drive Side Bearing to Frame |
53mm |
|
|
Hole |
Front28H/Rear32H |
|
|
Plait |
X3 Cross-over/ 32H |
|
Bearing |
Brand |
Japan EZO steel ball |
|
|
Sealed bearings |
Front6903*2/Rear6903*2/Cassette6803*2 |
|
Cassette Ratchet System |
Ratchet Type |
THR SSF Low Drag |
|
|
Ratchet Gear |
45/72T |
|
|
Angle |
8/5° |
|
Side Axle System |
Interface |
Straight Pull quick release axle with bearing pre-compaction adjust |
|
|
Installation |
Plug-in |
|
Seal Ring |
Non |
|
|
Cassette body model |
HG/XD/MS |
|
|
Usage Road |
XC/TR/AM/Enduro |
|
|
Weight |
325g Ti alloy cassette with pre-compaction |
|
|
Summarize |
Excellent Performance experience Bigger bearing and axle. Bran-new structural design Smooth/Simple/Fast |
|
